Description
The Ruthless Audio 800.4 is the do-everything full-size 4-channel amplifier in the lineup. Built on Korean Class-D technology, it delivers 220W × 4 at 2 ohms, 100W × 4 at 4 ohms, or 440W × 2 bridged at 4 ohms — enough flexibility for a full front/rear speaker stage, high-output mids, or a bridged 2-channel setup.
WHY CHOOSE THE RUTHLESS AUDIO 800.4?
- 220W × 4 @ 2Ω (14.4V) — strong per-channel power for upgraded components and pro-audio speakers.
- 100W × 4 @ 4Ω — clean headroom for traditional full-range systems.
- 440W × 2 Bridged @ 4Ω — bridge channels in pairs when more power per channel is needed.
- 1-Year 2Ω Warranty Coverage — standard manufacturer defect coverage includes operation down to 2 ohms per channel when warranty conditions are met.
- Korean Class-D Platform — efficient full-range output with serious power density.
- Clip Light Function — visual clipping feedback helps with gain setup and speaker protection.
- Wide-Range Crossovers — HPF and LPF controls with x10 multiplier let you tune mids, highs, or bridged applications without a basic one-size-fits-all crossover.
- Tiffany-Style RCA Inputs and 4 AWG power inputs for a clean, secure installation.
FULL SPECIFICATIONS
| RMS Power @ 4Ω (14.4V) | 100W × 4 |
| RMS Power @ 2Ω (14.4V) | 220W × 4 |
| Bridged Power @ 4Ω (14.4V) | 440W × 2 |
| Standard Warranty Load | Down to 2Ω per channel when warranty conditions are met |
| Amplifier Class | Korean Class-D |
| Channels | 4 (bridgeable to 2) |
| Operating Voltage | 8–16V |
| Input Sensitivity | 0.2V–6V |
| High-Pass Filter | 20Hz–800Hz / 200Hz–8kHz with x10 |
| Low-Pass Filter | 50Hz–800Hz / 500Hz–8kHz with x10 |
| THD | <0.01% @ 4Ω |
| RCA Inputs | Tiffany-style |
| Power Inputs | 4 AWG |
| Recommended Fuse | 100A |
| Clip Light | Yes |
AMPLIFIER & WIRING RECOMMENDATIONS
Use a quality 4 AWG OFC power and ground kit, solid low-resistance grounding, and proper fusing. Route RCA cables away from high-current power wiring, and make sure the vehicle’s charging system can maintain stable voltage when the amplifier is being driven hard.
Bridged operation requires a minimum 4-ohm load. Standard warranty coverage is down to 2 ohms per channel in stereo operation when all warranty requirements are met.
Operation below 11V and excessive clipping are not covered under warranty. Use the clip indicator as a warning tool and leave enough gain headroom for musical peaks and voltage changes.
FREQUENTLY ASKED QUESTIONS
Is the 800.4 warrantied at 2 ohms per channel?
Yes. The standard 1-year manufacturer defect warranty covers operation down to 2 ohms per channel when Ruthless installation and operating requirements are met.
Can I bridge the 800.4?
Yes. It is rated for 440W × 2 bridged at a 4-ohm load. Do not wire a bridged channel pair below 4 ohms.
What makes the 800.4 different from the Micro 800.4?
The full-size 800.4 uses the larger Korean Class-D platform, Tiffany-style RCA inputs, clip-light function, and the wider crossover system with the x10 multiplier. The Micro 800.4 prioritizes installation size and compact packaging.
What does the clip light do?
It gives you a visual warning when the amplifier output is clipping. It is useful during gain setup, but gains should still be set with headroom so normal music peaks do not drive the system into sustained clipping.
What can void warranty coverage?
Warranty does not cover vibration damage, wire or debris inside the amplifier, wiring below the covered impedance, external RCA damage, excessive clipping, or operation below 11V. Full warranty terms apply.
EXTENDED WARRANTY
No – Standard Warranty (1 Year)
Includes the standard 1-year manufacturer defect warranty, including covered operation down to 2 ohms per channel when all warranty requirements are met.
Yes – Extended Warranty (2 Years Total)
Adds 1 additional year of manufacturer defect warranty coverage for 2 years total.
