Description
The Ruthless Audio 4500.1 is a competition-grade tank built for abuse. Rated at 4,500W RMS at 1 ohm, stable down to 0.5 ohm, and strappable at 1 ohm, this full-size monoblock is made for high-output daily systems, demo vehicles, and SPL builds that need serious current capability and low-impedance flexibility.
WHY CHOOSE THE RUTHLESS AUDIO 4500.1?
- 4,500W RMS @ 1Ω (14.4V) — serious monoblock output for demanding subwoofer systems.
- 2,350W RMS @ 2Ω / 1,200W RMS @ 4Ω — usable power across multiple final loads.
- 1-Year 0.5Ω Warranty Coverage — Ruthless backs this full-size monoblock down to half ohm when warranty conditions are met.
- Strappable Design — run two 4500.1 amplifiers strapped at a 1-ohm final load when the system is designed for it.
- Tiffany-Style RCA Inputs — secure signal connections for high-output installs.
- Dual High-Current Power Feeds with 1/0 AWG inputs and 400A total recommended fusing.
- 10Hz–250Hz Frequency Response with 0–180° phase control for flexible subwoofer integration.
- Full-Size Heatsink — built to manage the heat generated by sustained high-current operation.
FULL SPECIFICATIONS
| RMS Power @ 1Ω (14.4V) | 4,500W |
| RMS Power @ 2Ω (14.4V) | 2,350W |
| RMS Power @ 4Ω (14.4V) | 1,200W |
| Minimum Covered Load | 0.5Ω |
| Strapped Load | 1Ω |
| Input Sensitivity | 0.2V–6V |
| Frequency Response | 10Hz–250Hz |
| Phase Control | 0–180° |
| THD | <0.01% @ 4Ω |
| RCA Inputs | Tiffany-style |
| Power Inputs | 1/0 AWG |
| Recommended Fusing | 400A total (200A per positive run) |
| Length | 25-1/8 in. |
| Width | 9-1/16 in. |
| Height | 2.75 in. |
ELECTRICAL & INSTALLATION
If you want full output — especially at 0.5 ohm — upgraded electrical is mandatory. Use a properly designed high-output charging system, Big 3 upgrade, sufficient AGM or lithium reserve, correctly sized OFC wiring, proper fusing, and low-resistance grounds.
The 4500.1 calls for 400A total fusing, 200A per positive run. Keep system voltage stable under load; operation below 11V is not covered under warranty.
Before wiring to 0.5 ohm or strapping amplifiers, calculate the final impedance of the complete subwoofer/voice-coil network. Wiring below the covered load is not warrantable.
FREQUENTLY ASKED QUESTIONS
Is the 4500.1 really covered at 0.5 ohm?
Yes. The standard 1-year manufacturer defect warranty covers operation down to 0.5 ohm when all Ruthless installation and operating requirements are met.
Can I strap two 4500.1 amplifiers?
Yes. The amplifier is designed to be strapped at a 1-ohm final load. Proper signal setup, matching gain, wiring, and electrical support are critical in a strapped system.
What electrical upgrades do I need?
The exact system depends on vehicle and use, but high-output charging, a Big 3 upgrade, adequate battery reserve, and full-size OFC power/ground wiring should be treated as part of the build — not optional extras.
What can void warranty coverage?
Warranty does not cover vibration damage, wire or debris inside the amplifier, wiring below the covered impedance, external RCA damage, excessive clipping, or operation below 11V. Full warranty terms apply.
EXTENDED WARRANTY
No – Standard Warranty (1 Year)
Includes the standard 1-year manufacturer defect warranty, including covered operation down to 0.5 ohm when all warranty requirements are met.
Yes – Extended Warranty (2 Years Total)
Adds 1 additional year of manufacturer defect warranty coverage for 2 years total.
