Description
-1.5k rms line
-1500w rms
-4k max on burp applications
-3″ American made PE coil
-4-layer alum flat wound
-300oz triple stack motor
-Heavy vented motor design
-12 spoke basket powder coated texture black
-4ga. Push terminals or upgradable 8ga. Ofc direct leads
-Black poly dust cap or upgradable real carbon fiber dust cap
-Big roll surround with red stitching
-4 layer progressive EM audio spider pack red on top with xl leads 3 black on bottom
-0.50″ basket spacer sleeves
-Hex head hardware
-2.5″ peak to peak xmax. 30mm 1-way
-Available in D2 or D4 coil configuration
.
-***recones are available for all sizes. Just ask.***-
-Mounting Depth: 8.75″
-Motor Width: 7.75″
-Cutout diameter:9.375″
-Outside diameter:10.25″
-Motor weight 31lbs
Box Specifications.
-1.0cu Sealed (10″)
-1.25cu Sealed (12″)
-1.50cu Sealed (15″)
-2.00cu Sealed (18″)
-2.0-2.5cu Ported @ 33-35hz (10-12″)
-2.5-3.0cu Ported @31-33hz (15″)
-4.0-5.0cu Ported @29-32hz (18″)
this is only recommended box size on rated power if you compete or run over rated power please get with your favorite box designer or builder to come up with something different.
Dave –
After some of the testimonies I’ve heard and read, these will be my next subs. I can’t wait to be the next in line! Seriously, if you can, get in line for these beautiful monsters!
